Handheld Dot Peen Marking Machine
The handheld dot peen marking machine is the on-site unit in our pin-marking range. Use it when the part is too heavy, large or fixed to put on a benchtop. A handheld stylus indents IDs on ferrous and non-ferrous metals in the shop, warehouse or field.
Best for
- Pipes, tanks, valves, structural steel, installed machinery
- VIN and chassis IDs where an indent is required
- Field service and outdoor marking with an optional magnetic base
Not for
- Nameplate batches at a bench (benchtop)
- Fine jewellery (gold fiber)
- High-speed conveyor codes (fly fiber or fly UV)
vs siblings
You carry this head to the workpiece. Benchtop stays on the table. VIN and chassis owns the VIN problem.
Benchtop dot peen · VIN and chassis marking · Deep metal marking · Dot peen family
Specs
| Parameter | Value |
|---|---|
| Marking area | 120 mm × 40 mm (customisable) |
| Marking depth | 0.1 mm – 1 mm (material dependent) |
| Operation | Handheld |
| Stylus | Pneumatic / electromagnetic |
| Power supply | 220V / 50 Hz |
| Controller | Built-in or PC-based |
| Communication | USB / serial / offline |
| Workpiece height | Up to 300 mm |
| Weight | About 7–12 kg (model dependent) |
| Materials | Ferrous and non-ferrous metals, some plastics |
Features
- Single-operator use on large objects
- Optional magnetic or adjustable base for alignment
- Logos, batch numbers, serials, QR and 2D codes
Materials
Metals including coated or uneven surfaces after a trial. Oily, rusty or highly curved areas need setup, not a catalogue promise.
Applications and industries
Accessories
Magnetic base, extra styli, controller options — specify on the quote.
Why this model
DPM without moving a 200 kg weldment onto a table.
FAQs
- Is it a “portable” in the H1?
- No. The product name is handheld. Portable was leftover copy on the old page.
- Laser VIN?
- Handheld fiber can mark contrast IDs. This machine is for an indented stamp. The job page compares them.
Tell us the part, the site conditions and how deep the ID must be.
