Handheld Fiber Laser Marking Machine
The handheld fiber laser marking machine is the gun-type unit in our fiber range. Use it when the part is too large, heavy or awkward to put under a desktop head. A compact controller and a handheld scan head mark metals and engineering plastics at 20–100W, 1064 nm.
Best for
- Chassis, frames, installed plant, oversized fabrications
- Vertical, overhead or curved surfaces the operator can reach
- Maintenance and field identification jobs
Not for
- Fine jewellery hallmarking (gold model)
- High-speed conveyor serialisation (fly)
- Deep VIN stamps that must be indented (handheld dot peen)
vs siblings
Same fiber source class as desktop. The difference is you take the head to the part.
Desktop fiber · VIN and chassis · Fiber family
Specs
| Parameter | Value |
|---|---|
| Laser power | 20W / 30W / 50W / 100W |
| Wavelength | 1064 nm ± 5 |
| Marking speed | Up to 15,000 mm/s (application dependent) |
| Marking field | 70×70 mm to 500×500 mm (lens options) |
| Min. line width | 0.01 mm |
| Min. character height | 1 mm |
| Repeat accuracy | ±0.01 mm |
| Laser source | IPG / JPT / Raycus / MAX |
| Cooling | Air-cooled |
| Software | EZCAD / HMI |
| Voltage | AC 220V, 50/60 Hz |
Features
- Gun-style head for reach
- Controller on table or trolley
- Optional focus bracket, extra lenses, rotary, trolley, exhaust
Materials
Engineering metals and markable plastics. Surface condition matters more than on a fixtured desktop — trial rusty, oily or painted areas.
Applications and industries
Accessories
Focus bracket, 70×70 / 150×150 / 300×300 mm lenses, rotary, trolley, exhaust.
Why this model
Full fiber mark on parts that never reach a cabin.
FAQs
- Welding machine?
- No. This is a marker. Welding is a separate family.
- Operator skill?
- Training required for focus, PPE and stable aim. We include install training from Coimbatore.
Tell us the part size and whether it can come to a bench.
