Portable Fiber Laser Marking Machine
The portable fiber laser marking machine is the box-type unit in our fiber range. Use it when the marker must move between cells or job sites. It marks metals and engineering plastics at 20–100W, 1064 nm, without a full desktop cabin.
Best for
- Shops with no spare floor for a cabin
- Service or multi-line work where the marker travels
- The same fiber quality as desktop, in a smaller footprint
Not for
- Dedicated high-volume station (desktop is simpler to fixture)
- True inline encoder marking (that is fly)
- Taking a gun to a chassis (that is handheld)
vs siblings
Portable is a compact box, not a handheld gun and not a fly head on a conveyor.
Desktop fiber · Fly fiber · Fiber family
Specs
| Parameter | Value |
|---|---|
| Laser power | 20W / 30W / 50W / 100W |
| Wavelength | 1064 nm ± 5 |
| Marking speed | Up to 15,000 mm/s (application dependent) |
| Marking field | 70×70 mm to 500×500 mm |
| Min. line width | 0.01 mm |
| Min. character height | 1 mm |
| Repeat accuracy | ±0.01 mm |
| Laser source | IPG / JPT / Raycus / MAX |
| Cooling | Air-cooled |
| Software | EZCAD |
| Voltage | AC 220V, 50/60 Hz |
Features
- Travel-friendly box layout
- Optional rotary, motorized Z, enclosure, fume extraction
- Low setup time between cells
Materials
Same metal and engineering-plastic range as desktop fiber. Trial coated or mirrored parts.
Applications and industries
Accessories
Rotary, F-theta lenses, motorized Z, safety enclosure, fume extraction.
Why this model
Industrial fiber mark without parking a full workstation on the line.
FAQs
- Is it a handheld?
- No. Handheld is a gun. This is a compact box.
- Line production?
- Possible for batched cells. Continuous moving parts → fly.
Tell us how often the marker must move, and what you mark.
